♦Voltage: AC110V-240V 50Hz-60Hz
♦ Lamp: HMI 1200W Jambo lamp
♦ Control channels: 32CH
♦ Control signal: DMX 512
♦ Control panel can control on/off of lamp
♦ 0-100%mechanical linear dimmer
♦ 1-10 times/s high speed strobe effect
♦ zoom 0-100%,
♦ iris 13°- 42°
♦ frost
♦ 1 color wheel, 7 color plus white light & CMY
wheel speed single way rainbow and
scrolling effect
♦ 2 gobo wheel, 5 fixing gobo plus 1 white
5 rotating goboplus 1 white
♦ The revolving gobos can be freely tuned
forward or backward, quickly or slowly
♦ Pan 540° and Tilt 280° scanning range,
smooth scanning action and accurate orientation
♦ Precise adjustment on horizontal and vertical
position
♦ 1 rotation 3facet prism effect, with prism
revolving effect
♦ According to kinds of safety standards, IP20
protect grades
♦ weight: 51.5KG
DMX Channels
CH1: Pan
CH2: Pan Fine
CH3: Tilt
CH4: Tilt Fine
CH5: Pan/Tilt Speed
CH6: Special Function
CH7: Pan/Tilt Macro
CH8: Pan/Tilt Macro Speed
CH9: Color Wheel
CH10: Cyan
CH11: Magenta
CH12: Yellow
CH13: Conversion filter
CH14: CMY Color Macro
CH15: Effect Speed
CH16: Effect Spd Assig
CH17: Gobo Wheel 1
CH18: Gobo 1 Indexing
CH19: Gobo 1 F.Indexing
CH20: Gobo Wheel 2
CH21: Gobo 2 Indexing
CH22: Gobo 2 F.Indexing
CH23: Effect Wheel
CH24: Effect Indexing
CH25: Effect F.Indexing
CH26: Frost
CH27: Iris
Ch28: Zoom
CH29: Focus
CH30: Shuter/Strobe
CH31: Dimmer
CH32: Dimmer Fine
