Speaker Section

Total Long-Term Power
400W RMS
Low Frequency Driver
12”, 75mm coil, 400W RMS
High Frequency Driver
1.4”, 75mm coil, 100W RMS
Frequency Response
72 Hz – 17.5 kHz  ±3 dB
Operation Frequency Range
54 Hz – 18 kHz
Maximum Peak SPL
134 dB
Dynamic Range
>112 dB
Coverage
100° Horizontal, 40° Vertical
Dimensions
588 X 372 X 384 mm (HXWXD)
Installation Facility
On Stand (35mm) + hanging points for all possible positions
Amplifier Section

Amplifier Input
Balanced XLR, 10KΩ
Input Sensitivity
0 dB for nominal output
Processing
Internal electronic crossover + Equalization
THD
1W-400W, <0.01%
Woofer Output Power
450W RMS
Tweeter Output Power
150W RMS
Total Output Power
600W RMS
Working Voltage
110 / 230V AC
Power Socket
Standard IEC
