Speaker Section

Maximum Power Handling
400W
Low Frequency Driver
10”
High Frequency Driver
1.7” Titanium
Frequency Response
50 Hz –  20 kHz  ±3 dB
Operation Frequency Range
45 Hz – 20 kHz
Sensitivity
93 dB
Rated Impedance
8 Ω
Maximum Peak SPL
130 dB
Dynamic Range
>112 dB
THD
<3%
Input Connector
NL 4
Coverage
55°-100° Horizontal, 50° Vertical
Dimensions
502 X 330 X 308 mm (HXWXD)
Installation Facility
On Stand (35mm) + hanging points for all possible positions
Weight
13.2 kg
