Number of Channels
Number of Channels: 48 inputs, 18 buses, 8 MATRIX, 58 out
AD/DA Conversion
Sample Rate: 48.0 kHz or 44.1 kHz
Signal Processing: 24 bits
Internal processing
Internal processing: 56 bits
Frequency Response
CONSOLE OUTPUT jacks (1 to 8)
    -2 dB / +0 dB(20k ohms load, +4 dBu)
    * Sample Rate: 48.0 kHz or 44.1 kHz
    * Input Connector: CONSOLE INPUT (Pad: ON, Input gain: +4 dBu, 20 Hz to 20 kHz)
PHONES jack
    -3 dB / +0 dB (40 ohms load, 130 mW)
    * Sample Rate: 48.0 kHz or 44.1 kHz
    * Input Connector: CONSOLE INPUT (Pad: ON, Input gain: +4 dBu, 20 Hz to 20 kHz)
Total Harmonic Distortion + Noise
CONSOLE OUTPUT jacks (1 to 8)
    0.05 % (typ., +4 dBu)
    * Sample Rate: 48.0 kHz or 44.1 kHz
    * Input Connector: CONSOLE INPUT (Pad: ON, Input gain: +4 dBu, 20 Hz to 20 kHz)
PHONES jack
    0.05 % (typ., 40 ohms load, 130 mW)
    * Sample Rate: 48.0 kHz or 44.1 kHz
    * Input Connector: CONSOLE INPUT (Pad: ON, Input gain: +4 dBu, 20 Hz to 20 kHz)
Dynamic Range
CONSOLE OUTPUT jacks (1 to 8)
    110 dB (typ.)
    * Sample Rate: 48.0 kHz or 44.1 kHz
    * Input Connector: CONSOLE INPUT (Pad: ON, Input gain: +4 dBu)
Cross Talk@ 1 kHz
CONSOLE INPUT jacks (1 to 8)
    -80dB (Pad: ON, Input gain: +10 dBu, typ.)
    * Sample Rate: 48.0 kHz or 44.1 kHz
CONSOLE OUTPUT jacks (1 to 8)
    -100 dB (typ.)
    * Sample Rate: 48.0 kHz or 44.1 kHz
Nominal Input Level (Variable)
CONSOLE INPUT jacks (1 to 8): -65 to -10 dBu (Pad: OFF) or -45 to +10 dBu (Pad: ON)
STEREO IN jacks (L / R): -18 to 0 dBu
TALKBACK MIC IN jack: -50 to -10 dBu
Pad
Pad: 20 dB ON / OFF
Input Impedance
CONSOLE INPUT jacks (1 to 8): 14 k ohms
STEREO IN jacks (L / R): 10 k ohms
TALKBACK MIC IN jack: 41 K ohms
Non Clip Maximum Input level
CONSOLE INPUT jacks (1 to 8): +8 dBu (Pad: OFF) or +28 dBu (Pad: ON)
STEREO IN jacks (L / R): +18 dBu
TALKBACK MIC IN jack: +8 dBu
Nominal Output Level
CONSOLE OUTPUT jacks (1 to 8): +4 dBu (Load impedance: 10 k ohms)
Output Impedance
CONSOLE OUTPUT jacks (1 to 8): 600 ohms
PHONES jack: 100 ohms
Recommended Load Impedance
CONSOLE OUTPUT jacks (1 to 8): 10 k ohms or greater
PHONES jack: 8 ohms or greater
Non Clip Maximum Output level
CONSOLE OUTPUT jacks (1 to 8): +22 dBu (1 kHz, 10 k ohms load)
PHONES jack: 150 mW + 150 mW (1 kHz, 40 ohms load)
Residual Noise Level (IHF-A, typ.)
    -88 dBu (All faders: Min)
    -80 dBu (Main Fader: Unity, Channel faders: Unity only one CONSOLE IN channel, Preamp gain: Min)
    -61 dBu (Main Fader: Unity, Channel faders: Unity only one CONSOLE IN channel, Preamp gain: Max)
    -73 dBu (All faders: Unity, Preamp gain: Min, S-1608 + S-4000S-3208, Total 48CH)
    -41 dBu (All faders: Unity, Preamp gain: Max, S-1608 + S-4000S-3208, Total 48CH)
    * Input 150 ohms terminate
    * Output Connector: CONSOLE OUTPUT jacks (1 to 8)
    * Sample Rate: 48.0 kHz or 44.1 kHz
Equivalent Input Noise Level (E.I.N.)
    -126 dBu (Main Fader: Unity, Channel faders: Unity only one CONSOLE IN channel, Preamp gain: Max)
    * Output Connector: CONSOLE OUTPUT jacks (1 to 8)
    * Sample Rate: 48.0 kHz or 44.1 kHz
Network Latency
    2.8 mS (typ.) *1

    * Total System Latency of audio signal from S-1608 inputs to outputs via M-380's REAC ports (A or B).

    * Sample Rate: 48.0 kHz
Connectors
CONSOLE INPUT jacks (1 to 8): XLR-3-31 type (balanced, phantom power)
TALKBACK MIC IN jack: XLR-3-31 type (balanced, phantom power)
STEREO IN jacks (L / R): RCA phono type
CONSOLE OUTPUT jacks (1 to 8): XLR-3-32 type (balanced)
PHONES jack: Stereo 1/4 inch phone type
DIGITAL OUT jacks x 2: Optical type, Coaxial type
Optical type, Coaxial type: RJ-45 EtherCon type
RS-232C connector: 9-pin D-sub type
MIDI connectors (OUT/THRU, IN): 5-pin DIN type
USB connectors: USB Type A and Type B
Display
    800 x 480 dots Wide VGA backlit TFT full color screen
Power Supply
    AC 115 V, AC 117 V, AC 220 V, AC 230 V, AC 240 V (50/60 Hz)
Power Consumption
    75 W
Accessories
    Power Cord
Size and Weight ( Desktop )
    Width: 482 mm
    Depth: 581 mm
    Height: 220 mm
    Weight: 14.0 kg
Size and Weight ( Rack mount )
    Width: 482 mm
    Depth: 231 mm
    Height: 551 mm
    Weight: 14.0 kg
