• High output SPL and sensitivity.
• 1x12" high power low frequency transducer with 75mm voice coil.
• Sensitivity 92dB, max SPL 123dB.
• RMS 300W, peak 1200W.
• Built-in power amplifier module.
• Master volume control.
• XLR input and output connectors.
• Built-in variable crossover 80Hz-250Hz high cut.
• Phase switch.
• Computer aided design to optimise frequency and phase response.
• Cabinet designed for FOH use.
• Suitable for use with any full range or mid/high speaker cabinets for extended low frequency, high quality music reproduction.
• Integral 35mm pole receptacle for mounting full range or mid/high speaker cabinet.
• Powder coated grill with foam backing.
• Durable Polyurethane textured base paint.

System Specifications:

Construction:	15mm Birch Plywood
Transducers:	1x12" LF
Frequency Response (-3dB):	40Hz-250Hz
Rated Power:	300W (RMS), 600W (Program), 1200W (Peak)
Amplifier Type	Class H
Sensitivity (1W @ 1m):	92dB
Maximum SPL (1W @ 1m):	118dB/124dB (peak)
Rated Impedance:	4 Ohms
Connector:	1x Combo 6.35/XLR Input, 1x XLR Output
Power Supply:	110V / 220V
Dimensions (WxDxH):	460mm x 452mm x 370mm
Packaging Dimensions (1 piece/pack):	550mm x 550mm x 470mm
Net Weight (1 piece/pack):	22.5 kg
Gross Weight (1 piece/paek):	24.5 kg
