Technical data

Speaker Type: 2-Way Active Speaker
Acoustical data

Frequency Response [-10dB]: 60 - 20.000 Hz
Frequency Response [+/- 3dB]: 68 - 19.000 Hz
Max SPL: 128 dB
HF: 1 "
Type HF: Neodymium Compression driver / Titanium voice coil
Voice Coil HF: 1.75 "
Directivity: 80/65 x 60 °
Horn: Asymmetrical CD Horn
LF: 10 "
Type LF: Neodymium
Voice Coil: LF 2.5 "
Amplifier

Amp Technology:  digipro
Amp Class:  Class D
Power PRG: 900 W
HF Amp: 200 W/RMS
LF Amp: 400 W/RMS
Cooling: Convection

Processor

Controller: DSP / 24bit/48kHz
System Presets: Flat / Processed
Limiter: Dual Active / Peak, RMS, thermal
Delay Option: No
Crossover Frequency MF-HF: 1940 Hz
Slope MF-HF: 24 dB/Octave
Input Section

Signal Input: 1x XLR / 1x 6.3mm phone jack
Microphone Input: Yes
Signal Output: 1x XLR / 1x 6.3mm phone jack
Power Socket: VDE
Voltage Range: 240 V
Mechanics

Housing: PP
Housing Design: Multifunctional
Color: Black
Handles: 1x on top
Pole Mount: 36mm
Angles Up: Monitor use 43 °
Front Grille: Metall, 1.2mm with acoustical foam
Rigging Points: No
Flytracks: No
Width: 343 mm
Height: 553 mm
Depth: 304 mm
Weight: 9.9 kg
